如果你会建网站,你就能建桌面应用。
如果你会写 JavaScript 代码,确实可以构建一个外观和行为都与原生应用无异的桌面应用。不仅如此,你还可以将 Angular 的强大功能引入桌面应用领域,让你的用户界面 (IU) 看起来惊艳无比 😍。好了,不多说了,去泡杯咖啡,我们开始吧!
我们该怎么办?!
我们将使用Electron和Angular构建一个基本的桌面应用程序。
在开始之前,我假设您已经具备Node.js和Angular的一些基本知识。
设置 Angular
如果您尚未安装 Angular CLI,请运行以下命令进行安装。
$ npm install -g @angular/cli
现在让我们创建一个新的Angular应用程序。
$ ng new angular-electron
它会询问你想使用哪个样式编译器,以及是否要使用 Angular 路由器等等,这些配置完全无关紧要,选择你想要的任何选项即可。
您现在可以通过运行以下程序来查看您的应用程序的实际运行效果……
$ cd angular-electron
$ ng serve
然后打开浏览器访问http://localhost:4200/,不过这还不是最有趣的部分,我们继续往下看。
我们需要修改项目 src 文件夹中的 index.html 文件,在 base 标签中添加一个句点,以便我们的应用程序可以找到静态文件,不要跳过这一步,这非常重要。
<base href="./">
设置 Electron
现在我们要把 Electron 添加到我们的应用程序中。
$ npm install --save-dev electron
我们还需要一些依赖项。
$ npm install --save-dev app-root-path
现在让我们为 Electron 应用程序创建一个新文件夹。
$ mkdir bin && cd bin && touch main.ts
如您所见,我们创建了一个 bin 文件夹main.ts,其中包含一个文件。之所以将主文件创建为带有 .tsts扩展名而不是 .ts 扩展名,js是因为我们已经在 Angular 应用程序中使用 TypeScript,那么为什么不在整个项目中都使用 TypeScript 呢?
现在让我们往main.ts文件中添加一些代码(终于要写代码了😅)
import { app, BrowserWindow } from 'electron';
import { resolve } from 'app-root-path';
// Keep a global reference of the window object, if you don't, the window will
// be closed automatically when the JavaScript object is garbage collected.
let win: BrowserWindow;
function createWindow () {
// Create the browser window.
win = new BrowserWindow({
width: 800,
height: 600
});
// Load the angular app.
// Make sure that this path targets the index.html of the
// angular application (the distribution).
win.loadFile(resolve('dist/angular-electron/index.html'));
// Emitted when the window is closed.
win.on('closed', () => {
// Dereference the window object, usually you would store windows
// in an array if your app supports multi-windows, this is the time
// when you should delete the corresponding element.
win = null;
});
}
// This method will be called when the Electron has finished
// initialization and is ready to create browser windows.
// Some APIs can only be used after this event occurs.
app.on('ready', createWindow);
// Quit when all windows are closed.
app.on('window-all-closed', () => {
// On macOS it is common for applications and their menu bar
// to stay active until the user quits explicitly with Cmd + Q
if (process.platform !== 'darwin') {
app.quit();
}
});
app.on('activate', () => {
// On macOS, it's common to re-create a window in the app when the
// dock icon is clicked and there are no other windows open.
if (win === null) {
createWindow();
}
});
// In this file, you can include the rest of your app's specific main process
// code. You can also put them in separate files and require them here.
上面的代码与官方网站上提到的完全相同,但使用的是 Typescript 语法,还要注意win.loadFile链接到 Angular 应用程序入口文件的函数“我们还没有构建它”。
好吧,我们需要检查一下我们这样做是否真的有效,对吧!
让我们在package.json文件中添加一个脚本,以便构建和运行这个应用程序。
"main" : "bin/main.js",
"scripts": {
...
“electron”: “tsc bin/main.ts && ng build && electron bin/main.js”
}
现在让我们来看看它的实际效果。
$ npm run electron
目前你应该可以看到应用程序已经启动并运行,其中包含 Angular 标志,到目前为止一切顺利 😉。
好了,现在我们的应用程序已经运行了,但是我们可以在Angular应用程序内部使用Electron API吗?!!
别慌,其实很简单,只要跑就行了……
$ npm install --save-dev ngx-electron
从 Angular 应用程序内部访问 Electron API。
我们刚刚安装了ngx-electron,它将使我们的工作轻松许多,那么让我们看看如何使用它。
我们需要像在 Angular 文件中使用其他模块一样导入这个模块app.module.ts。
import { NgxElectronModule } from 'ngx-electron';
@NgModule({
imports: [
...
NgxElectronModule
]
})
export class AppModule {}
好了,现在我们可以把它用在我们的组件里了,比如……
import { ElectronService } from 'ngx-electron';
export class AppComponent {
constructor(private _electronService: ElectronService) {
// now we have access to electron api through this service
}
}
我们来看看是否真的可以访问 Electron API。
请将文件中的内容替换app.component.ts为以下内容。
import { Component } from '@angular/core';
import { ElectronService } from 'ngx-electron';
@Component({
selector: 'app-root',
templateUrl: './app.component.html',
styleUrls: ['./app.component.scss']
})
export class AppComponent {
title = 'angular-electron';
versions = { node: '', chrome: '', electron: '' };
constructor(private _electronService: ElectronService) {
// Make sure that app is being executed inside of electron.
if (this._electronService.isElectronApp) {
// We have access to node process.
this.versions.node = this._electronService.process.versions.node;
this.versions.chrome = this._electronService.process.versions.chrome;
this.versions.electron = this._electronService.process.versions.electron;
}
}
}
并将文件内容替换app.component.html为以下内容。
<!--The content below is only a placeholder and can be replaced.-->
<div style="text-align:center">
<h1>Welcome to {{ title }}!</h1>
<ul>
<li>Node version {{ versions.node }}</li>
<li>Chrome version {{ versions.chrome }}</li>
<li>Electron version {{ versions.electron }}</li>
</ul>
</div>
所以,你觉得怎么样?别想太多,让我们看看实际效果吧😅。
$ npm run electron
现在,你应该可以看到应用程序已经运行起来了,使用了我们所使用的代码、Chrome 和 Electron 版本,嗯,我们成功了 😉。
结论
开发桌面应用程序并不难,我们可以使用像 Node、Angular、Electron 和 TypeScript 这样强大的工具来完成出色的工作。你知道吗?即使你是 Web 开发人员,在空闲时间尝试一些新技术也不错,我确信你会从尝试新技术中学到一些新东西 😉。
如果我有空的话,我可能会写一篇新文章,介绍如何为我们的应用程序编写一些单元测试。
如果遇到问题,您可以随时参考此应用程序的Github 代码库。
